Data connection with

Siemens S7

  • Direct S7 connection: Connect to Siemens PLC without detours using the RFC1006 protocol
  • Visualization in real time: Display relevant control data immediately on the HMI
  • Flexibly expandable: Can be combined with data from SAP, OPC UA, MQTT and more
Production employees view a dashboard with real-time data from a Siemens S7 controller — visualized with Peakboard for transparent PLC visualization.

Do it like ZARGES

This is how ZARGES uses the Siemens S7 data connection from Peakboard to efficiently visualize real-time data:
Martin Lemmer
Head of IT EMEA at ZARGES
“Easy implementation and use was important to us. Peakboard offered many standards in the SAP environment and was able to integrate all data sources without programming effort. In addition, even before making the decision, I noticed that we could use the graphical interface intuitively and easily adapt it. ”

Integrated Siemens S7 interface

With Peakboard, you can visualize data from Siemens S7 controllers (e.g. SIMATIC S7-300, S7-1200 or S7-1500) directly on a dashboard — without a TIA portal, engineering know-how or additional software. Your PLC data is recorded live, evaluated and visualized together with other sources such as SAP, OPC UA or MQTT. Peakboard supports the S7 protocol (RFC1006) and enables direct communication with your PLC. You can not only read process data, but also write it back if necessary — e.g. for confirmations or manual control commands.

  • Direct connection to Siemens S7 control systems
  • Easy configuration via Peakboard Designer
  • Real-time communication without middleware
  • Access to data blocks, variables & byte offsets

Visually display PLC data — for maximum transparency

Whether it's a fault display, meter reading, operating status or HMI elements: With Peakboard, you can visualize relevant control data on modern dashboards — visually, comprehensibly and in real time. Use conditional formatting, color codes, and automatic alerts for immediate response on the shop floor.

Combine & expand — beyond the PLC

Peakboard is more than classic PLC visualization software. Link your Siemens data to other systems, such as:

  • ERP (e.g. SAP)
  • MES
  • OPC UA server
  • IoT platforms (Azure, AWS, Google Cloud)

This gives you a holistic view of your manufacturing processes — from control to management.

Why Peakboard is the smart solution for your PLC visualization

With Peakboard, you benefit from a particularly intuitive PLC visualization — without complex programming. Thanks to seamless integration into existing automation technology, the solution can be easily integrated into existing Siemens S7 controllers and industrial networks. It can be set up in no time, and thanks to the flexible expandability, you can adapt your system to new requirements at any time. The visualization takes place directly at the scene — via modern HMI displays, which provide your employees with exactly the information they need.

Mach's wie ZARGES

So nutzt ZARGES die Siemens S7-Datenanbindung von Peakboard zur effizienten Visualisierung von Echtzeitdaten:
Implementation with Peakboard: View and automatically process existing and newly generated data in real time

Start now for free with Peakboard Designer

Capture, process and visualize production and order data in real time — simply and without programming knowledge.

Mockup eines Desktop-Monitors mit geöffneter Peakboard Designer Software, die eine Benutzeroberfläche zur Produktionsüberwachung zeigt. In der Mitte ist ein Dialogfenster zur Datenbindung eines Textfelds geöffnet, um Prozentwerte aus einer Datenquelle anzuzeigen.

All of your data.

Peakboard connects your systems and brings all data to one platform — for visualization, automation and individual applications.

Save time with our templates

No time for long designs? No problem: Use one of the many ready-made templates for dashboards and applications — e.g. for production monitoring, warehouse management or quality assurance. Pick a template, customize it, and you're done.
